KLCOB V2 Series

1.25 – 1.56mm LED video display for indoor use

LED Screen for
Demanding Environments

The Absen KLCOB V2 Series is a premium high-resolution indoor LED screen designed for environments where image quality, reliability and performance are essential. It uses advanced COB technology (Chip on Board), delivering high brightness, deep blacks and excellent colour reproduction.

The modular 16:9 design makes it easy to adapt the LED screen to different sizes and formats. Built for stable operation and long service life, the KLCOB V2 Series combines high contrast with easy cleaning and enhanced resistance to impact, dust and moisture. The result is a smooth, sharp and consistent image, even in challenging lighting conditions.

Functionality

High image quality

Up to 3,840 Hz refresh rate delivers sharp, lifelike colors and smooth transitions.

Slim profile

Only 39.3 mm deep, lightweight and easy to install, including LED modules and accompanying cables.

Multiple installation options

Can be mounted on a wall for a sleek look, hung from the ceiling for open areas, or built freestanding.

Easy installation and service

Magnetic module connection for quick installation and easy service from the front.

KLCOB V2 Series Specifications

Optical

Pixel Pitch: 1.25 | 1.56mm
Type of LED: Flip-chip COB LED
Pixel density: 640 000 px/m2 | 409 690 px/m2 |
Pixel resolution: 480×270 | 384×216
Brightness: 600 – 1 000 nit
Contrast ratio: 15 000:1
Viewing angle: 160° H | 160° W
Refresh rate: 3 840 Hz
Material: Die-cast aluminum
Dimensions: 600×337.5×39.3 mm
Weight: 4.5 kg
Service: Front
IP rating: IP40/IP21
Control unit: NovaStar
Receiving card: NovaStar
Data connection: EtherCON
Power supply: AC 100-240V 50/60 Hz
CCC, CE, CB, ROHS, FCC, ETL, PSE, CQC
2 year
