Absen
NX Series

1.5 – 2.5mm LED video display for indoor use

Absen

Premium SMD display for
TV studios and on-camera use

Absen NX Series is our most advanced SMD video display for installations where image quality, color reproduction, and on-camera performance are key priorities. The series is particularly well suited for high-end TV studios, control rooms, corporate studios, and other professional productions where the LED video display is used as a backdrop or appears directly on camera.

The slim 16:9 design makes it easy to build displays in standard video formats, while the flexible panel sizes support both flat and creative installations. For productions with particularly demanding camera requirements, we can also offer other display solutions optimized for even lower drive modes.

Functionality

Developed for on-camera use

A refresh rate of up to 7680 Hz delivers a stable image without visible scan lines during recording and live broadcasting.

Natural colors

Advanced color calibration and high grayscale performance at low brightness preserve tones and details in controlled studio environments.

Flexible installation

The display can be wall-mounted, suspended, or floor-mounted, with support for corners, cubes, and concave display surfaces.

Tailored to the production

For demanding productions, we also offer displays with lower drive modes tailored to the cameras and frame rates.

NX Specifications

Optical

Pixel Pitch: 1.5mm | 1.875mm | 2.5mm
Type of LED: Black SMD
Resolution: 640×360 | 512×288 | 384×216
Brightness (nit): 800 nit
Grayscale (bit): 16 bit
Contrast ratio: 4000:1 | 4000:1 | 4500:1
Viewing angle: 160° H | 160° W
Refresh rate (Hz): 7 680 Hz
Drive mode: 1/45 | 1/36 | 1/27
Material: Die-cast aluminum
Dimensions: 960x540x43.5 mm
Weight: 20 kg / sqm
Service: Front
IP rating: IP40/IP21
Control unit: NovaStar
Receiving card: NovaStar
Data connection: Ethernet
Power Consumption (max): 420W / sqm
Power Consumption (avg): 140W / sqm
FCC, ETL, CE, RoHS, CCC, TUV
2 years
